Gold silver and other precious metals smelting
- Type:DSGP-30
- Max output power:30kw
- Max output current:50A
Gold silver and other precious metals smelting
Application:
1. Machine tool guide quenching;
2. Gear Quenching: sprocket, transmission gear, etc .;
3. Car and motorcycle parts quenching: ball cage, ball head, car shock absorber rod, shift fork and so on;
4. Crane parts quenching: rotating bearing block, rotating bearings, etc .;
5 annealing and tempering: tungsten vacuum annealing;
6. Stainless steel bright annealing: stainless steel bellows, stainless steel straight tube;
7. Standard parts forging heating: bolts, nuts, etc .;
8. Hardware tools forging heating: wrenches, pliers, etc .;
9. Building heating parts forging: construction fasteners, etc .;
10. Gold and silver and other precious metals melting;
11. Alloy tools, saw blade brazing;
-
-
Workpiece nameGold silver and other precious metals
-
Processing technologySmelting
-
Equipment typeDSGP-30
-
Equipment power30KW
-
Working current range30-50A
-
Working frequency range12-16KHz
-
Smelting capacity5Kg
-
Smelting time15min
-
TypeDSGP-30
-
Working principleElectromagnetic induction heating
-
Max output power30KW
-
Max output current50A
-
Working voltage range380V±10%
-
Input power3×380V/50-60HZ
-
Oscillation frequency10-35KHz
-
Power factor0.95
-
Temperature protection55℃
-
Working efficiency100%
-
Coil materialscopper tube
-
Output power moduleinfineon
-
Cooling methodwater cooling
-
Cooling water qualityindustrial pure water or soften water
-
Cooling water pressure≧0.3Mpa
-
Cooling water temperature≦38℃
-
IGBTInfineon
-
Air witchCHINT
-
Rectifier bridgeChangzhou Ruihua
-
A.C contactorCHINT
-
Absorption capacitorCelem
-
Filter capacitorFeitai
-
Resonant capacitorAntai
-
Integrated circuitTI(Texas Instruments) и ADI(Analog Devices,lnc.)
-
Optical fiberAvago
-
Low voltage apparatusSchneider Electric
-
Touch screenKinco
-
Magnetic coreXian Sanlian
-
Copper materialLuotong
Power equipment working parameters
Power equipment basic parameters
Power main components configuration
-
-
-
1.Oсобые замечаниея технологиев продукцией и соотрудничеств
Порядок работ;Условия поставки:
-
2.How to choose the right induction heating equipment?
Induction heating equipment has two main technical parameters: output power and operating frequency
-
3.How to install and operate induction heating equipment?
We will provide the installation video and detailed Russian English instructions to guide the installation
-
4.Which countries and regions is your machine exported to?
As a specialized factory in the field of induction heating, we are always committed to providing customers with stable and reliable products with quality assurance
-
5.How is your after-sales service?
If necessary, we will send technical personnel for site instruction
-
6.How to extend the service life of Medium Frequency melting furnace?
First of all, when the first use of medium frequency melting furnace, it is necessary to make a lining in medium frequency furnace and sinter it
-
7.The difference between medium frequency induction furnace and resistance furnace
In modern industrial production, for workpiece heating,must do heat treatment, welding, smelting and other processing, each process is essential of product quality
-
